Technical and technical specifications for a large diesel generator from Perkins
|Number of Cylinders||3|
|Cylinder Arrangement||Vertical in line|
|Bore and Stroke mm||77 x 81|
|Displacement / Cubic Capacity liters||1.131|
|Induction System||Naturally Aspirated|
|Combustion System||Indirect Injection|
|Rotation||Anti-clockwise, viewed on flywheel|
|Cooling System||Water – cooled|
|Frequency and Engine Speed||50Hz & 1500rpm|
|Gross Engine Power kW (hp)||8.6 (11.5)||9.5 (12.7)|
|Fuel Consumption @ 50% load L/hr
@ 75% load L/hr
@ 100% load L/hr
|Total Lubrication System Capacity liters||4.9||4.9|
|Total Coolant Capacity (inc. radiator) liters||5.2||5.2|
|Exhaust Temperature: °C||368||420|
|Radiator Cooling Air Flow (Min): m3/sec||0.44||0.44|
|Combustion Air Flow: m3/min||0.7||0.7|
|Exhaust Gas Flow: m3/min||1.66||1.8|
|Fuel Tank Capacity: liters||58||58|
Perkins four stroke heavy duty high performance
industrial type diesel engine.
- ENGINE FILTRATION SYSTEM
• Air filter.
• Fuel filter.
• Full flow lube oil filter.
All filters have replaceable elements.
- COOLING RADIATOR
Radiator and cooling fan, complete with safety
guards, designed to cool the engine at high ambient
temperatures (consult your dealer for de-ration factors)
- EXHAUST SYSTEM
Heavy duty Industrial Exhaust Silencer
- CIRCUIT BREAKER TYPE
ABB 2 pole MCB. (3 pole is optional)
|Silencer noise reduction level||22 (dB)|
|Maximum allowable back pressure||10.0 (kPa)|
STANDARD REFERENCE CONDITIONS :
Output ratings are presented at 25°C air inlet temperature, barometric pressure 100 kPa, relative humidity 30%.
This generating set is designed to operate at high ambient temperatures (up to 55°C), humidity (up to 99%) and higher altitudes.
De-ration may apply, please consult your dealer for specific site ratings.
Some of the specifications are not standard on all Genset models.
AVAILABLE OPTIONS & ACCESSORIES
commercially purchased power. 10% overload power is available for 1 hour in 12 hours continuous
We offer a range of optional features and accessories to tailor our generating sets to meet your power needs.
- A variety of generating set control and synchronizing panels
- Genuine spare parts
- Additional protection alarms and shutdowns
- Load banks
- Water fuel seperator
- Auxiliary fuel tanks
- Water jacket heater
- Manual & automatic transfer
- Battery charger switches
